PAL36
Overview
Features
Specifications:
System: 3-way 4-unit bass reflex
Rated Power: 250W
Maximum Power: 500W
Nominal Impedance: 4 OHMS
Recommended Amplifier: 300W-500W@4 OHMS
Sensitivity (1W@1m): 98dB
Maximum SPL: 122dB@250W (125dB@500W)
Frequency Range (-6dB): 80Hz-20KHz
Coverage (-6dB): H1000XV400
Transducers:
Neodymium MF, LF Driver 6.5″ (165mm dia. 75mm magnet 38mm voice coil)×3
Neodymium HF Driver 1.4″ (70mm magnet 36mm voice coil)×1
Crossover Model: Passive
Connector: SPEAKON NL4×1 (PIN1+/2+POS. PIN1-/2-NEG); 2 PIN connecting Terminal×1
Cabinet Material: 15mm (0.60″) high-quality plywood
Color: The default is black, other colors can be customized as required.
Cabinet Size: W697*D190*H220mm
Package Size: W860*D260*H300mm
Weight: 9.75kg
Recommended Applications: Suitable for multi-function hall, command center, small band performance, small conference room, electronic classroom and other fixed installation
