PAL24
Overview
Features
Specifications:
System: 2-way 3-unit bass reflex
Rated Power: 70W
Maximum Power: 140W
Peak Power: 280W
Nominal Impedance: 8 OHMS
Recommended Amplifier: 150W-250W@4 OHMS
Sensitivity (1W@1m): 92dB
Maximum SPL (Pmax@1m): 110dB@70w (116dB@280w)
Frequency Range: 90Hz-17KHz
Coverage (-6dB): 70°H×20°V
Transducers: Ferrite LF Driver 4″ (38mm voice coil, 90 Ferrite)×2
Ferrite HF Driver 1″ (36mm voice coil, 90 Ferrite)×1
Crossover Model: Passive
Connector: SPEAKON NL4×1 (PIN1+=POS. PIN1-=NEG) 4-pin Phoenix terminal×1
Cabinet Material: 12mm (0.47″) high-quality plywood
Cabinet Size: W140mm*D160mm *H410mm
Color: The default is black water-based point coating
Weight: 4.7kg
Recommended Applications: Suitable for multi-function hall, command center, small band performance, small conference room, electronic classroom and other fixed installation
