PAL44
Overview
Features
Specifications:
System: 2-way 5-unit bass reflex
Rated Power: 130W
Maximum Power: 260W
Peak Power: 520W
Nominal Impedance: 8 OHMS
Recommended Amplifier: 200W-300W@8 OHMS
Sensitivity (1W@1m): 96dB
Maximum SPL (Pmax@1m): 117dB@130w (123dB@520w)
Frequency Range (-10db): 100Hz-18KHz
Coverage (-6dB): 70°H×30°V
Transducers: Ferrite LF Driver 4″ (25mm voice coil 90 Ferrite)×4
Ferrite HF Driver1″ (25mm voice coil 70 Ferrite)×1
Crossover Model: Passive
Connector: SPEAKON NL4×1 (PIN1+=POS. PIN1-=NEG) 4-pin Phoenix terminal ×1
Cabinet Material: 12mm (0.47″) high-quality plywood
Cabinet Size: W140mm*D160mm*H700mm
Color: The default is black water-based point coating
Weight: 6.2kg
Recommended Applications: Suitable for multi-function hall, command center, small band performance, small conference room, electronic classroom and other fixed installation
