Specifications:

System: 2-way 2-unit front bass reflex

Rated Power: 400W

Maximum Power: 800W

Peak Power: 1600W

Nominal Impedance: 8 OHMS

Recommended Amplifier: 500W-700W@8 OHMS

Sensitivity (1W@1m): 97dB

Maximum SPL: 123dB@400w (129dB@1600w)

Frequency Range (-6dB): 48Hz-18KHz

Coverage (-6dB): 90°H×60°V

Transducers: Ferrite HF Driver1.7″ (44mm voice coil 115 Ferrite)×1

Ferrite LF Driver15″ (75mm voice coil 180 Ferrite)×1

Crossover Model: Passive

Connector: SPEAKON NL4×2 (PIN1+/2+POS.  PIN1-/2-NEG)

Cabinet Material: 18mm (0.7″) MDF

Color: The default is black eco-friendly water-based point coating

Cabinet Size: W440*D450*H710mm (including feet 716mm)

Weight: 27.2kg

Recommended Applications: Suitable for multi-function hall, auditorium, lecture hall, conference room KTV, bar, and other fixed installation
