Specifications:

System: 2-way 2-unit front bass reflex

Rated Power: 300W

Maximum Power: 600W

Peak Power: 1200W

Nominal Impedance: 8 OHMS

Recommended Amplifier: 400W-600W@8 OHMS

Sensitivity (1W@1m): 96dB

Maximum SPL: 120dB@300w (126dB@1200w)

Frequency Range (-6dB): 62Hz-18KHz

Coverage (-6dB): 90°H×60°V

Transducers: Ferrite HF Driver 1.7″ (44mm voice coil 115 Ferrite)×1

Ferrite LF Driver 12″ (65mm voice coil 156 Ferrite)×1

Crossover Model: Passive

Connector: SPEAKON NL4×2 (PIN1+/2+POS.  PIN1-/2-NEG)

Cabinet Material: 15mm (0.6″) high-quality MDF

Color: The default is black eco-friendly water-based point coating

Cabinet Size: W370*D390*H610mm (including feet 616mm)

Weight: 19.45kg

Recommended Applications: Suitable for multi-function hall, auditorium, lecture hall, conference room KTV, bar, and other fixed installation
