GLA210
Overview
Features
Specifications:
System: 2-way 3-unit bass reflex
Rated Power: 700W (LF: 600W, HF: 100W)
Music Power: 1400W (LF: 1200W, HF: 200W)
Peak Power: 2800W (LF: 2400W, HF: 400W)
Nominal Impedance: 8 OHMS (LF: 8Ω, HF: 8Ω)
Sensitivity (1W@1m): 102dB (LF: 102dB, HF: 112dB)
Maximum SPL (Pmax@1m): 131dB@700W (137dB@2800W)
LF:130dB@600W (136dB@2400W)
HF:132dB@100W (138dB@400W)
Frequency Range(-10 dB): 58Hz-18KHz (LF: 58Hz-3.5KHz, HF: 600Hz-18KHz)
Coverage (-6dB): Single array module is 90ºH*8ºV
(Note: The vertical coverage angle of the linear array varies depending on the degree and curvature of the array.)
Adjustable Angle: 0°～ 10°, Unit Adjustable Angle1°
Recommended Number of Line Array: ≥4pcs
Rated Parallel Number: ≤2pcs
Transducers: Ferrite LF Driver 10″ (65mm voice coil 170 Ferrite)×2
Ferrite HF Driver 3″ (75mmvoice coil 165 Ferrite)×1, 1.5″ Horn
Crossover Model: Switchable Active or Passive Frequency
Connector: SPEAKON NL4×2 Passive: PIN1+/POS. PIN1-/NEG.
Active: PIN1+/LF+、PIN1-/LF-; PIN2+/HF+、PIN2-/HF-
Cabinet Material: 15mm (0.7″) high-quality plywood
Suspension Hardware: Professional suspension fixture of adjustable angle
Color: The default is polyurea coating, other colors can be customized as required
Cabinet size: W711mm*D500mm*H305mm
Weight: 35.64kg/38.2kg
Recommended Applications: Small outdoor performance amplification, theater, auditorium main amplification
