GLA208
Overview
Features
Specifications:
System: 2-way 4-unit bass reflex
Rated Power: 400W (LF: 320W, HF: 80W)
Music Power: 800W (LF: 640W, HF: 160W)
Peak Power: 1600W (LF: 1280W, HF: 320W)
Nominal Impedance: 16 OHMS (LF: 16Ω, HF: 16Ω)
Sensitivity (1W@1m): 99dB (LF: 99dB, HF: 109dB)
Maximum SPL (Pmax@1m): 125dB@400W (131dB@1600W)
LF: 124dB@320W (130dB@1280W)
HF: 128dB@80W (134dB@320W)
Frequency Range(-10 dB): 65Hz-18.5KHz (LF: 65Hz-4KHz, HF: 900Hz-18.5KHz)
Coverage (-6dB): Single array module is 90ºH*8ºV
(Note: The vertical coverage angle of the linear array varies depending on the degree and curvature of the array.)
Adjustable Angle: 0°～ 10°, Unit Adjustable Angle1°
Recommended Number of Line Array: ≥4pcs
Rated Parallel Number: ≤4pcs
Transducers: Ferrite LF Driver 8″ (50 mm voice coil 140 Ferrite)×2
Ferrite HF Driver 1.4″ (36mm voice coil 90 Ferrite)×2, 1″ Horn
Crossover Model: Switchable Active or Passive Frequency
Connector: SPEAKON NL4×2 Passive: PIN1+/POS. PIN1-/NEG.
Active: PIN1+/LF+、PIN1-/LF-; PIN2+/HF+、PIN2-/HF-
Cabinet Material: 15mm (0.7″) high-quality plywood
Suspension Hardware: Professional suspension fixture of adjustable angle
Color: The default is polyurea coating, other colors can be customized as required
Cabinet Size: W593mm*D355mm*H239mm
Weight: 30.7kg/32.6kg
Recommended Applications: Small outdoor performance amplification, theater, auditorium main amplification
