●8IN/8OUT digita matrix processor.
●32 bit SHARC DSP, 96kHz sampling rate, 24 bit  AD/DA.
● +48V phantom power, MIC/LINE input gain switchable, MIC input sensitivity adjustable.
●Input including: low-cut, independent feedback inhibition, PEQ, noise gate, gain, mute, phase, link adjustment and volume adjustment.
●Output including X-over, PEQ, Gain, mute, compressor/miter, phase, delay, link adjustment and volume adjustment.
●All PEQ Gain, bandwidth, frequency continues adjustment. Type can be select by PEAK, H-SHELF, L-SHELF, LOW CUT, HIGH CUT, ALLPASS1, ALLPASS2.
●All inputs/outputs can do Matrix, and all the input and output channel name can be changed.
●All the input and output with independent phase curve adjust function, PEQ style  choose ALLPASS1 is 180° curve adjust, ALLPASS2 is 360° curve adjust.
● All high cut, low-cut filter type can be select by Butterworth, Link witz-Riley, Bessel, slope can be chosen.
●Noise gate's threshold, time, ratio can be adjustment for inputs, compessor, limite, ratio, time can be adjustment for outputs.
●Maximal delay time 680mS for all input/output channels.
●Pre settings can copy for every single channel, every channel can do linkadjust.
●Every input and output channel PEQ curve adjusting picture can be found when you are in any input and  output.
●Unique AUX special channel design，can mix all the microphone channel, has powerful feedback and processional ECHO&REVERB dual engine multiple effector, can beautify tone and also can perfectly support karaoke effector requirement, very suitable for conference rooms,
multifunctional halls and so on.
● AUX channle has powerful mixing function, such as threshold, level, attack time. release time, continually adjustment. also with the automatic function of camera-tracking. threshold, level, attack&release time. Etc... And also with independent PEQ processing function.
●Inside single generator(pink,white noise and 20~20K sine wave,  amplitude adjustable ).
● Front panel has level indicator for input/output , USB port, RS232,485 and
net ports remote control at rear panel. Easy for user's operations.
●21user presets can be save and recall, maximal 256 units can be link
together via ID settings. Password protection function for high level applications.
●Frequency：20Hz - 20kHz -0.3dB
●S.N：>115dB
●THD：<0.005 @ 1kHz （0dBu)
●Dimension：W480mm x D205mm x H45mm
