Specifications:

System: 2-way 3-unit full-range bass reflex

Rated Power: 200W

Maximum Power: 400W

Peak Power: 800W

Nominal Impedance: 8 OHMS

Recommended Amplifier: 300W-450W@8 OHMS

Sensitivity (1W@1m): 94dB

Maximum SPL: 117dB@200w (123dB@800w)

Frequency Range (±3dB): 115Hz-12KHz

Coverage (-6dB): 90°H×90°V

Transducers: Ferrite HF Driver 1.4″ (36mm voice coil, 90mm Magnet)×1

Ferrite LF Driver 6.5″ (38mm voice coil, 120mm Magnet) ×2

Crossover Model: Passive two-way

Connector: SPEAKON NL4×2  (PIN1+/POS  PIN1-/NEG)  terminal block ×1

Cabinet Material: 15mm (0.6″) +12mm (0.47″) high-quality plywood

Color: The default is black eco-friendly water-based coating

Product Size: W192mm*D245mm*H495mm

Weight: 5.0kg

Recommended Applications: Suitable for multi-function hall, auditorium, lecture hall, conference room and other fixed installation.
