System: 2-way 2-unit constant-voltage / constant-impedance bass-reflex system

Rated Power (Low-Impedance): 60W

Maximum Power (Low-Impedance): 120W

Peak Power (Low-Impedance): 240W

Power Taps (Constant Voltage): 70V   45W/30W/15W/7.5W

100V  60W/30W/15W

Nominal Impedance: 8 ohms

Sensitivity (1W@1m): 90dB

Maximum SPL: 107dB@60W(113dB@240W)

Coverage (-6dB): 90°H×90°V

Frequency Range (-10dB): 60Hz－30kHz

Crossover Model: Passive

Transducers:

Neodymium HF Driver 0.75” (25mm voice coil 46 Ferrite 0.75” Horn)×1

Ferrite LF Driver 6.5” (38mm voice coil 100 Ferrite)×1

Input Connection: 4-pin Phoenix terminal

Cabinet Material: White ABS front baffle, 1.2 mm black metal rear housing. White slim metal grille with magnetic mounting

Overall Dimensions: Φ265*219mm, Installation depth is greater than 214mm

Cutout Size (Reference): Φ225mm (Φ222~230mm)

Mounting Method: Four-point clamp mounting

Net Weight: 4.2kg

Recommended Applications: Language amplification system for conference room, backstage sound reinforcement for the small banquet hall, background music in public places such as shopping malls and waiting halls
